●     24 Well Crystallization Plate                                                                 top
        Description:
            o    For hanging drop vapor diffusion crystallization.
            o    Classic Linbro-like footprint to hold large hanging drop and reservoir.
            o    It can be used for initial crystallization screening and growth of large crystals.
            o    It has good optical properties and strong resistance to most of chemicals.
            o    To perform hanging drop vapor diffusion crystallization, use cover slides to mount the hanging drop and use
                       grease to seal the well (not included).
        Items:
  Catalog number   Product name   Description
  CB-01   24 well plate   24 well, φ16.5mm, 150 ×106×28mm (with lid)
  Data Sheet   Price:   Contact Us
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
  •    482 Well Crystallization Plate                                                             top
    		•
            Description:
                o        For sitting drop vapor diffusion crystallization.
                o    48 reservoir wells with 2 corresponding sample drop wells.
                o    Compatible with both multi-channel pipettes.
                o    Footprint meets microplate SBS standards for automation.
                o    Recommended volumes: 100 μl for the reservoir well (maximum 200 μl) and 1 to 2 μl for the sample drop
                           wells.
                o    Excellent optic properties and strong resistance to most of chemicals.
                o    Wide (1.75-3.5 mm) well walls gives excellent tape sealing properties, and makes it possible to open and
                           re-seal a well.
            Items:
      Catalog number   Product name   Description
      CB-02   482 well plate   48 reservoir well, 96 sample drop well, SBS standard
       micro-plate
      Data Sheet   Price:   Contact Us
    --------------------------------------------------------------------------------------------------------------------------------------------------------------------
  •    96f Well Crystallization Plate                                                           top
    		•
            Description:
                 o For sitting drop vapor diffusion crystallization.
                o 96 well plate. Each well contains a reservoir well and a flat sitting drop surfaces which are good for a single or
                       double sample drops.
                o A large (3.8x7.6mm) sitting drop area suitable for both automatic drop dispensing and manual plate setup.
                o The plate has the standard SBS footprint, is suitable for using automatic drop dispensing and imaging robot.
                 o Recommended volumes: 70 μl for a reservoir well (max. 200 μl) and from 50 nanoliters to 1 μl for a sample
                       drop.
                o When crystallization solution contains low molecule weight hydrophobic reagents like isopropanol, a small
                       drop volume is highly recommended (<200 nanoliters).
                o 9 mm well spacing makes it easy to use a multichannel pipette.
                o Excellent optic properties and strong chemical resistance.
                o The reservoir wall with 1.4 mm in thickness provides a good tape sealing space, and also makes it easy to
                       open and re-seal a well.
            Items:
      Catalog number   Product name   Description
      CE-03   96f well crystallization plate   96 reservoir well, 96 sample drop well, SBS standard
      micro-plate
      Data Sheet   Price:   Contact Us
    --------------------------------------------------------------------------------------------------------------------------------------------------------------------
  •    XtalFinder                                                                                              top
    		•

    ——Automatic, high-speed protein crystallization imaging system, is suitable for imaging SBS standard plates. The system allows both manual snapshots of single drop and automatically scanning and imaging a SBS plate. The scanning and imaging a 96 well plate needs only about 2 minutes.
            Description:
                 o Highly automatic imaging system, suitable for any available SBS footprint plate.
                o Manual control interface provides complete control of movement and snapshot functions.
                o Accurate X, Y, Z-translation with a smallest step size of 1.25 μm.
                o High speed imaging needs only 2 min to scan a 96 well plate.
                o Control software is built on PC window operation system. Its GUI is clear and user-friendly.
                o 0.65 to 4.5X zoom lens unit (additional 2X lens included).
                o VGA quality (768x576 pixels) color CCD camera.
                o LED Cold light source. o Single or multiple slicing option for imaging.
                o Simple GUI input to allow user to add new type of plates for imaging.
            Items:
      Catalog number   Product name   Description
      CBS-01   XtalFinder   Automatic, high-speed protein crystallization imaging
      system
      Data Sheet   Price:   Contact Us
