Holey Carbon Cryo-EM Grid, R1/1, Cu/Ni/Au Mesh(GIG-1010)
Inquiry
| Cat.No. | Product Name | Size | Price | Qty |
|---|---|---|---|---|
| GIG-1010 | Holey Carbon Cryo-EM Grid, R1/1, Cu/Ni/Au Mesh |
|
||
| Add to Quote Order Request a Bulk Order | ||||
| Product Summary | |
|---|---|
| Name | Holey Carbon Cryo-EM Grid, R1/1, Cu/Ni/Au Mesh |
Download Datasheet
|
|
| Cat No. | GIG-1010 |
| Product Overview | GIG holey carbon grids are lithographically precision-manufactured supports for cryo-electron microscopy (cryo-EM), featuring photolithographically defined circular holes on an ultra-thin amorphous carbon film (10–12 nm). Designed for single-particle analysis (SPA), electron tomography (ET), and micro-electron diffraction (MicroED), GIG grids deliver consistent hole geometry, minimal background scattering, and reliable sample vitrification across all four hole patterns (R1/1, R1.2/1.3, R2/1, R2/2). Available in copper, nickel, and gold mesh with 200, 300, and 400 mesh options. Trusted in peer-reviewed cryo-EM publications achieving resolutions from 2.7 Å to 3.9 Å (2011 to present). |
| Storage | Room temperature (sealed, dry); avoid humidity and light |
| Hole Diameter | 1 µm |
| Hole Spacing | 1 µm |
| Center Distance | 2 µm |
| Hole Pattern Type | R1/1 |
| Mesh Material | Cu; Ni; Au |
| Mesh Options | 200/300/400 |
| Grid Diameter | 3.05 mm |
| Carbon Film Thickness | 10–12 nm |
| Compatibility | Compatible with FEI/Thermo Fisher EPU, SerialEM, Leginon, cryoSPARC Live. Fits all standard cryo-EM autoloaders (Titan Krios, Glacios, Talos Arctica, JEOL CRYO ARM). Standard 3.05 mm grid diameter — drop-in replacement for commercial holey carbon grids. |
| Applications | Single-particle cryo-EM (SPA); electron tomography (ET); micro-electron diffraction (MicroED); structural biology of membrane proteins, protein complexes, ribosomes, viruses; high-resolution structure determination; automated high-throughput cryo-EM data collection. |
| Pack Size | 50 grids/box; 100 grids/box |
